SQC1P-S4-SO
SQC 1/4 in. x 1/4 in. Tube Outside Diameter Quick Connect Stem (SESO)
Specifications
| Cv Coefficient | 0.4 |
|---|---|
| End Size | 44200in |
| End Type | Array |
| Flow [Max] | 4gpm, 15L/min |
| Inch/Metric | Inch |
| Insertion Depth | 1.09in, 27.7mm |
| Plug Series | SO |
| Pressure Rating 316 Stainless Steel with Fluorocarbon (FKM) O-Ring at 70 (20 ?C) Temperature | 206bar, 3000psig |
| Pressure Rating 316 Stainless Steel with Fluorocarbon (FKM) O-Ring at 400 (204 ?C) Temperature | 17.2bar, 250psig |
| Spillage | 0.3cm? |
Dimensions
| Dimension F | 15.9mm |
|---|
Description
(SQC1P-S4-SO)
SQC 1/4 in. x 1/4 in. Tube Outside Diameter Quick Connect Stem (SESO)
Simple push-pull action to connect and disconnect lines-no tools required. Plug and body are available valved or unvalved. Valves automatically open when connected and shut off when disconnected to minimize the loss of liquids or gases.
