UHP Reducing 90° Elbow
UHP Reducing 90° Elbow
- Model: SM6X4E19 (3/8″ O.D. to 1/4″ O.D. elbow)
- Type: Reducing 90° Elbow
- Material: 316 Stainless Steel (corrosion-resistant alloy)
- Pressure Rating: Built for high-pressure fluid systems
- Size: 3/8″ O.D. x 1/4″ O.D. (Outer Diameter)
- Finish: Smooth machined for clean transitions
Specifications
Compatibility
This part may be used in place of the following parts from other manufacturers:
| Bi-Lok (Series D)® |
|---|
Available Sizes
SM6X4E19 – Stainless Steel 3/8″ O.D. x 1/4″ O.D. Reducing 90° Elbow UHP Reducing 90° Elbow
- Model: SM6X4E19 (3/8" O.D. to 1/4" O.D. elbow)
- Type: Reducing 90° Elbow
- Material: 316 Stainless Steel (corrosion-resistant alloy)
- Pressure Rating: Built for high-pressure fluid systems
- Size: 3/8" O.D. x 1/4" O.D. (Outer Diameter)
- Finish: Smooth machined for clean transitions
SM8X4E19 – Stainless Steel Reducing 90° Elbow – 1/2″ O.D. x 1/4″ O.D. UHP Reducing 90° Elbow
- Model: SM8X4E19 (1/2" O.D. to 1/4" O.D. elbow)
- Type: Reducing 90° Elbow
- Material: 316 Stainless Steel (corrosion-resistant alloy)
- Pressure Rating: Optimized for high-pressure fluid systems
- Size: 1/2" O.D. x 1/4" O.D. (Outer Diameter)
- Finish: Polished for clean bends
SM8X6E19 – Stainless Steel Reducing 90° Elbow – 1/2″ O.D. x 3/8″ O.D. UHP Reducing 90° Elbow
- Model: SM8X6E19 (1/2" O.D. to 3/8" O.D. elbow)
- Type: Reducing 90° Elbow
- Material: 316 Stainless Steel (corrosion-resistant alloy)
- Pressure Rating: Rated for high-pressure fluid systems
- Size: 1/2" O.D. x 3/8" O.D. (Outer Diameter)
- Finish: Machined for clean transitions
SM12X4E22 – Stainless Steel Reducing 90° Elbow 3/4″ O.D. x 1/4″ O.D. UHP Reducing 90° Elbow
- Model: SM12X4E22 (3/4" O.D. to 1/4" O.D. elbow)
- Type: Reducing 90° Elbow
- Material: 316 Stainless Steel (corrosion-resistant alloy)
- Pressure Rating: Optimized for high-pressure fluid systems
- Size: 3/4" O.D. x 1/4" O.D. (Outer Diameter)
- Finish: Polished for clean curves
SM12X6E22 – Stainless Steel Reducing 90° Elbow – 3/4″ O.D. x 3/8″ O.D. UHP Reducing 90° Elbow
- Model: SM12X6E22 (3/4" O.D. to 3/8" O.D. elbow)
- Type: Reducing 90° Elbow
- Material: 316 Stainless Steel (corrosion-resistant alloy)
- Pressure Rating: Rated for high-pressure fluid systems
- Size: 3/4" O.D. x 3/8" O.D. (Outer Diameter)
- Finish: Machined for clean transitions
SM12X8E22 – Stainless Steel 3/4″ O.D. x 1/2″ O.D. Reducing 90° Elbow UHP Reducing 90° Elbow
- Model: SM12X8E22 (3/4" O.D. to 1/2" O.D. elbow)
- Type: Reducing 90° Elbow
- Material: 316 Stainless Steel (corrosion-resistant alloy)
- Pressure Rating: Optimized for high-pressure fluid systems
- Size: 3/4" O.D. x 1/2" O.D. (Outer Diameter)
- Finish: Polished for clean curves
SM16X4E23 – Stainless Steel 1″ O.D. x 1/4″ O.D. Reducing 90° Elbow UHP Reducing 90° Elbow
- Model: SM16X4E23 (1" O.D. to 1/4" O.D. elbow)
- Type: Reducing 90° Elbow
- Material: 316 Stainless Steel (corrosion-resistant alloy)
- Pressure Rating: Rated for high-pressure fluid systems
- Size: 1" O.D. x 1/4" O.D. (Outer Diameter)
- Finish: Machined for clean transitions
SM16X8E23 – Stainless Steel Reducing 90° Elbow – 1″ O.D. x 1/2″ O.D. UHP Reducing 90° Elbow
- Model: SM16X8E23 (1" O.D. to 1/2" O.D. elbow)
- Type: Reducing 90° Elbow
- Material: 316 Stainless Steel (corrosion-resistant alloy)
- Pressure Rating: Optimized for high-pressure fluid systems
- Size: 1" O.D. x 1/2" O.D. (Outer Diameter)
- Finish: Polished for clean curves
SM16X12E23 – Stainless Steel Reducing 90° Elbow – 1″ O.D. x 3/4″ O.D. UHP Reducing 90° Elbow
- Model: SM16X12E23 (1" O.D. to 3/4" O.D. elbow)
- Type: Reducing 90° Elbow
- Material: 316 Stainless Steel (corrosion-resistant alloy)
- Pressure Rating: Rated for high-pressure fluid systems
- Size: 1" O.D. x 3/4" O.D. (Outer Diameter)
- Finish: Machined for clean transitions
