SBV210-S-8
Stainless Steel Ball Valve – 1/2" Tube x Tube, Butterfly Handle, 1000 psi
- Model: SBV210-S-8 (1/2" tube OD x 1/2" tube OD)
- Type: 2-Way Compression Ball Valve with Butterfly Handle
- Material: 316 Stainless Steel (corrosion-resistant alloy)
- Pressure Rating: 1000 psi (maximum working pressure)
- Handle Type: Low-profile butterfly handle
- Finish: Machined and passivated for hygienic and industrial pressure systems
| Cv Coefficient | 9.5 |
|---|---|
| End Size | 44198in |
| Inch/Metric | Inch |
| Operating Temperature [Max] | ?F |
| Operating Temperature [Min] | ?F |
| Orifice | 9.0mm |
| Pressure Rating | 69bar, 1000psig |
| Pressure [Max] | 1000psi |
| Dimension A | 101.4mm |
|---|---|
| Dimension H | 34.0mm |
| Dimension I | 90.0mm |
| Dimension L | 48.0mm |
Stainless Steel Ball Valve – 1/2" Tube x Tube, Butterfly Handle, 1000 psi (SBV210-S-8)
The SBV210-S-8 is a stainless steel 2-way ball valve built for clean shutoff in moderate-pressure fluid systems. Designed with 1/2" tube outside diameter (OD) compression ends and a compact butterfly handle, this valve is ideal for confined spaces, panels, or systems requiring low-torque operation.
Constructed from 316 stainless steel, the SBV210-S-8 delivers long-term performance in both sanitary and industrial environments. With a working pressure of up to 1000 psi, it’s suitable for general-purpose liquid and gas flow applications where durability, ease of installation, and corrosion resistance are critical.
Its full port design ensures minimal pressure drop, while the PTFE seat maintains consistent shutoff across temperature swings. The butterfly handle enables fast quarter-turn actuation without interfering with adjacent system components, making it popular in instrumentation setups, valve banks, and Original Equipment Manufacturer (OEM) assemblies.
Key Benefits
- 1000 psi pressure rating for mid-pressure shutoff applications
- 316 stainless steel body resists corrosion and vibration
- Compact butterfly handle saves panel space and enables low-clearance installation
- PTFE seat provides reliable leak-tight performance
- Full-port design supports maximum flow with minimal restriction
- Easy to install and fully reusable in field-serviceable systems
Typical Applications
- Instrumentation manifolds and gas panels
- Original Equipment Manufacturer (OEM) assemblies and skids
- Low-torque flow control in confined enclosures
- Water, air, inert gas, and mild chemical lines
- General-purpose shutoff for sanitary or industrial tubing
The SBV210-S-8 gives you reliable mid-pressure control and 316 stainless steel durability—without the premium price.
